• Astra F30 — The Elite 30ft Flat Roof Family Home

    Spacious 58㎡ Modular Living with a Sleek, Contemporary Edge

    • Generous 58㎡ Interior: A true full-scale residential solution with a massive 9-meter length, comfortably accommodating 2-3 bedrooms.
    • Modern Flat Roof Design: A clean, minimalist architectural silhouette that excels in both urban settings and natural retreats.
    • Upgraded Insulation: Features 100mm thick EPS insulated wing roofs for superior thermal protection and energy efficiency.
    • Rapid Unfolding System: Precision-engineered 130mm hinges allow for a full setup in under 15 minutes with minimal labor.
    • Starting from $14,800 USD

  • Why Astra F30?

    Architectural Excellence

    The flat roof design provides a consistent internal ceiling height and a high-end look that complements modern luxury developments.

    Logistics Optimized

    Engineered to fold to a 2.2m width, allowing a full 58㎡ home to be shipped within a single 40HQ container.

    Durable Construction

    Hot-galvanized steel frame with electrostatic white powder baking ensures 20+ years of structural integrity and corrosion resistance.

    Optional Sloped Roof

    For regions with high rainfall or snow, we offer an optional secondary sloped roof upgrade for enhanced drainage and a traditional aesthetic.

  • Technical Specifications

    Customizations for local building codes and extreme climates are available upon request.

    Dimensions & Space

    • External Dimensions (Open): 9000mm (L) x 6420mm (W) x 2450mm (H)
    • External Dimensions (Folded): 9000mm (L) x 2250mm (W) x 2450mm (H)
    • Internal Dimensions: 8550mm (L) x 6260mm (W) x 2210mm (H)
    • Total Area: 58 ㎡
    • Weight: Approx. 3.5–3.8 Tons

    Structure & Materials

    • Main Frame: Hot-dip galvanized steel with electrostatic spraying (Pure White).
    • Wall Panels: 65mm EPS color steel composite panels (0.3mm double-sided steel).
    • Main Roof: 50mm EPS color steel composite board + 0.45mm corrugated steel veneer.
    • Wing Roof: Upgraded 100mm EPS insulation for superior heat protection.
    • Flooring: 18mm Bamboo glue board base with 4.0mm SPC stone plastic finish.

    Openings & Hardware

    • Entrance Door: High-security broken-bridge aluminum or fire-rated steel door.
    • Windows: Aluminum alloy or plastic-steel double-glazing sliding windows.
    • Hinges: 130mm heavy-duty galvanized embedded hinges.

    Electrical & Systems

    • Standard: Pre-installed CE/UL/SAA compliant electrical systems.
    • Capacity: Integrated 12KW system with LED lighting and international sockets.
    • Utilities: Pre-wired and pre-plumbed for immediate "Plug-and-Play" site connection.

    Kitchen & Bathroom

    • Bathroom: Fully integrated wet/dry separation layout with smart toilet and vanity.
    • Configuration: Supports multiple 2-bedroom or 3-bedroom interior floor plans.
  • Detailed specifications and features of Astra F30 modern 30ft flat roof house.

    Features Highlight:

    • Expandable Design: Innovative folding mechanism for rapid deployment.
    • Space Efficient: 58㎡ footprint optimized for maximum usable area.
    • Eco-Friendly: Sustainable materials and energy-efficient insulation.
    • Quick Installation: Fully operational within 15 minutes of arrival.

  • Layouts & Vision

    3D & Top-Down Layouts

    The F30 features a flexible floor plan with a central living area, dedicated kitchen & dining space, two bedrooms, and a full bathroom.

    Logistics

    Loading quantity is 1 Set per 40HQ container. Folded dimensions are 9000 x 2250 x 2450mm.
