• Astra E10 — The Ultimate 10ft Premium Expandable Home

    Rapid-Deployment Modular Space for Modern Living

    • Meticulous Engineering: High-precision galvanized steel frame with electrostatic spraying and white powder baking for maximum corrosion resistance and aesthetic finish.
    • Spacious Studio Layout: Unfolds to a generous 18.5m² (approx. 200 sq. ft.) area—ideal for a full studio apartment with kitchen and bathroom options.
    • High-Performance Insulation: 65mm thick EPS composite wall panels and polyurethane-insulated flooring for superior thermal and acoustic comfort (A2 Fire Class).
    • Logistics Powerhouse: Compact folded width of 2.2m allows 4 units to fit into a single 40HQ container, slashing international shipping costs.
    • Start from $5,000

  • Why Choose the Astra E10 10ft Expandale House?

    Future-Forward Living, Elevated Above the Horizon

    The Astra E20 20ft expandable house redefines the possibilities of modular small-space living. Featuring a precision-engineered 20ft double-wing folding mechanism, this expandable container home transforms from a standard shipping size into a spacious 37m² luxury prefab house in under 3 hours.

    Industrial-Grade Durability

    Features 130mm galvanized embedded hinges and a 1.2mm steel plate bottom protection for 10,000+ folding cycles and 20+ years of use.

    Eco-Friendly Luxury

    Standardized production with recycled materials and SPC stone-plastic flooring for a healthy, VOC-free interior.

    Versatile Applications

    From high-end resort glamping pods to rapid-response emergency housing and portable site offices.

  • Technical Specifications

    Customizations for local building codes and extreme climates are available upon request.

    Dimensions & Space

    • External Dimensions (Open): 2950mm (L) x 6300mm (W) x 2480mm (H)-
    • External Dimensions (Folded): 2950mm (L) x 2200mm (W) x 2480mm (H)
    • Internal Dimensions: 2510mm (L) x 6140mm (W) x 2240mm (H)
    • Total Area: 18.5 m²
    • Weight: Approx. 1,300–1,500 kg

    Structure & Material

    • Main Frame: Electrostatic spraying / white plastic powder baking process on high-strength galvanized steel.
    • Wall Panels: 65mm thick Type 950 double-sided 0.3mm EPS color steel composite panel.
    • Roof: 50mm EPS color steel composite board + 0.45mm corrugated steel veneer (Exterior).
    • Flooring: 18mm Bamboo glue board + 4mm SPC stone plastic flooring with 1.2mm steel bottom plate.

    Openings & Hardware

    • Main Door: High-security broken-bridge aluminum or fire-rated steel door.
    • Windows: 4x Aluminum alloy or plastic-steel double-glazing sliding windows.
    • Hinges: 130mm heavy-duty galvanized embedded hinges.

    Electrical & Systems

    • Standard: Pre-installed CE/UL/SAA standard electrical systems.
    • Capacity: 12KW, 32A leakage protector with integrated LED lighting.
    • Bathroom (Optional): Can be pre-fitted with integrated smart toilet, vanity, and shower module.
  • Modern modular container house presentation showing a 20ft expandable unit with interior photos, a top-down 3D layout, bathroom detail, exterior view, and a technical floor plan; layout includes a living room, dining area, kitchen, bathroom, and two bedrooms within a compact rectangular structure.

  • Layouts & Lifestyle

    Lifestyle Note

    The 10ft footprint allows for incredibly agile deployment in restricted sites, while the interior offers a full-scale living experience comparable to high-end apartments.
